One furnace three parts machine

1

Mould opening rate

5～12 moulds(Times) /min

2

Lead furnace max. capacity

570kg

3

Lead furnace heater

220V   12kw

4

Lead laddle heater

3 roll 380V   3.0kw

5

Motor

220V 40W

Speed reducer

1/40

6

Mould cylinder

SC80×100

7

Fliping cylinder

MAL32×100

8

Cutting cylinder

SDA 100×30

9

Lead bucket safty sys. cylinder

MALJ32×35-30

10

Lead furnace cylinder

SDA40×25

11

Mould clamping pressure

4～6kgf/cm²

12

Air input

0～1MPa

13

Air Flow

0.15ｍ³/min

14

Machine dimension (LxWxH)

1600×930×2200(mm)

15

Machine Weight

About 512kg

16

Packing dimension (LxWxH)

1700×1050×2300(mm)

17

Packing weight

About 612kg
